S1T

☆ Compact and Flexible, Multi-Scene Use, with Detachable Base for Easy Fixed Installation

☆ WiFi Connection, AP Connection, Loop Recording, Motion Detection

☆ HD 1920 x 1080P

☆ Built-in 800mAh Polymer Lithium Battery

☆ 940nm Infrared Night Vision, No Light Emission in Complete Darkness

Item

Category

Parameter

System

Operating System

Linux

Number of Online Users

4 users can watch online simultaneously

APP

FOWL / O-KAM

Acquisition

Processor

Ingenic T23

Memory

8M

Image Sensor

2MP CMOS / 1080P

Minimum Illumination

0.3-0.5 Lux (Color Mode), 0 Lux (Black and White Mode)

Lens

Lens Diameter 10mm, 4G Lens

Viewing Angle

(H)110°, (D)140°

Night Vision

Black and White Night Vision, 6 pieces of 940nm Non-Luminous Patch Infrared Lamps, Irradiation Distance 3-5 Meters

Video

Compression Standard

H.264+/H.264/MJPEF/JPEG

Multi-Stream

Main Stream: 1080P/15fps Sub-Stream: 360P/15fps

Bit Rate

Two Bit Rate Control Modes: CBR/VBR, Output Bit Rate Range: 128～4096kbps

Image Adjustment

Brightness, Contrast, Vertical and Horizontal Adjustment Available, OSD Display

Audio

Input

Built-in －38dB Microphone

Output

/

Sampling Frequency/Bit Width

8KHz/16bit

Compression Standard/Bit Rate

G711A

Network

Wireless Connection

Add via Device QR Code / AP Connection, Wi-Fi Connection / Bluetooth Connection

Wireless Network

IEEE802.11b/g/n

Wireless Frequency

2.4~2.4835GHz

Wireless Security Encryption

64/128-bit WEP/WPA-PSK/WPA2-PSK Digital Encryption

Storage

External TF Card

Supports Maximum 256GB Memory Card

Cloud Storage

Paid Cloud Storage

Power Supply

Rated Voltage

DC 5V±5%

Power Supply

Built-in 800mAh Polymer Lithium Battery

Working Duration

Approximately 3 Hours of Battery Life After Power Outage

Working Environment

Operating Temperature: -10～55℃, Operating Humidity <90%

AI

Alarm Detection

Motion Detection Alarm

Human Shape Detection

/

Packaging

Product Size

3.4x3.4cm, 118g per Set

Packaging Size

6.45.89.8cm

Carton Packaging

50.334.519.5cm, 100pcs/CTN, 12.4KG/CTN
